Thermometry Camera Xtherm
Thermometry Camera Xtherm

Thermometry Camera Xtherm

Thermometry Camera Xtherm

As the first smartphone attached thermal imaging camera by Infiray, Xtherm brings you a whole new camera experience. With the USB type-C interface, the Xtherm can be directly connected to smartphones, tablets, computers and other devices that support this interface. With APP or PC software, Xtherm enables real-time thermal image display and temperature statistics etc.

Meet  Xtherm Series


The Xtherm Series is an ultra-portable infrared camera for smartphone that opens up smart life. With few steps, it can not only create excellent imaging effects, but also capture temperature in real time which makes it a reliable companion for outdoor observation, camping, survival in the wild and home use.




High Image Quality

Embedded with IRay 384 × 288 / 17μm vanadium oxide VOx detector, the Therm series provides clear images and makes searching in darkness much easier.




High Frame Rate

25Hz frame rate output, capable of capturing every wonderful moment during the nights.



Germanium Single Crystal Alloy Lens

F1.0 large aperture lens to enhance image quality.



Superior Temperature Measurement Accuracy

Equipped with a unique temperature measurement algorithm, and professional-level thermal analysis software, high accuracy of temperature measurement, meeting various types of temperature and thermal analysis needs.


Ultralow Power Consumption <500mK

Battery-free design and long endurance usage for every charge.



Hot Target Tracking

High/low temperature spot tracking are supported as well as any three points of temperature measurements.

Environmental Compensation Correction

Environmental compensation correction guarantees more accurate temperature measurement in various environments.


Plug-and-Play, Easy to Operate

The Therm series can connect to a smartphone or tablet with the free APP via the Type-C interface.

Secondary Development

SDK is provided to facilitate secondary development for customization in various industries.



  • Xtherm T2S
  • Xtherm T3S
  • Xtherm T3Pro
Resolution,  pixels240×180
Pixel size, μm17
NETD, mk≤60@25℃,f#1.0
MRTD, mk≤500@25℃,f#1.0
Objective Lens, mm6.8
Frame Rate, Hz25
FOV(field of view), °34.8°x26.8°
Digital Zoom/
Operating Temp. Range-10℃~+50℃
Temp. Measuring Rang-20℃~+120℃
Temp. Measuring Accuracy±3℃or±3% of temperature measuring range
Temp. CorrectionManual/Auto
Power Consumption, mW<500
Weight (with lens), g<40
Dimension (with lens), mm49.5*26*27.5
Phone CompatibilityAndroid 6.0 or above*
Image EnhancementDigital enhancement
Image CalibrationManual/Auto(per 3 min when no manual operation)
Color PaletteWhite hot/Black hot/Multiple pseudo color  options
SDK DevelopSupport
Temp. StatisticsSupport max./min./center temp.  display, with up to three spots statistics
Photo & VideoSupport photos/ video storage .etc
Online Software UpdateSupport



Resolution, pixels384×288
Pixel size, μm17
NETD, mk≤60@25℃,f#1.0
MRTD, mk≤500@25℃,f#1.0
Objective Lens, mm6.8
Frame Rate, Hz25
FOV(field of view), °55.7°x41.6°
Digital Zoom/
Operating Temp. Range-10℃~+50℃
Temp. Measuring Rang-20℃~+120℃
Temp. Measuring Accuracy±3℃or±3% of temperature measuring range
Temp. CorrectionManual/Auto
Power Consumption, mW<500
Weight (with lens), g<40
Dimension (with lens), mm49.5*26*30
Phone CompatibilityAndroid 6.0 or above*
Image EnhancementDigital enhancement
Image CalibrationManual/Auto(per 3 min when no manual operation)
Color PaletteWhite hot/Black hot/Multiple pseudo color options
SDK DevelopSupport
Temp. StatisticsSupport max./min./center temp.  display, with up to three spots statistics
Photo & VideoSupport photos/ video storage .etc
Online Software UpdateSupport


Resolution, pixels384×288
Pixel size, μm17
NETD, mk≤60@25℃,f#1.0
MRTD, mk≤500@25℃,f#1.0
Objective Lens, mm13
Frame Rate, Hz25
FOV(field of view), °28.4°x21.4°
Digital Zoom/
Operating Temp. Range-10℃~+50℃
Temp. Measuring Rang-20℃~+120℃(extended to 400℃)
Temp. Measuring Accuracy±2℃or±2% of temperature measuring range
Temp. CorrectionManual/Auto
Power Consumption, mW<500
Weight (with lens), g<40
Dimension (with lens), mm49.5*26*30
Phone CompatibilityAndroid 6.0 or above*
Image EnhancementDigital enhancement
Image CalibrationManual/Auto(per 3 min when no manual operation)
Color PaletteWhite hot/Black hot/Multiple pseudo color options
SDK DevelopSupport
Temp. StatisticsSupport max./min./center temp.  display, with up to three spots statistics
Photo & VideoSupport photos/ video storage .etc
Online Software UpdateSupport


  • Product Parameters Comparison
  • ModelXtherm   T2SXtherm  T3SXtherm   T3Pro
    Resolution, pixels240×180384×288384×288
    Pixel size, μm17
    NETD, mk≤60@25℃,f#1.0
    MRTD, mk≤500@25℃,f#1.0
    Objective Lens, mm6.813
    Frame Rate, Hz25

    FOV(field of view), °34.8°x26.8°55.7°x41.6°28.4°x21.4°
    Digital Zoom/

    Operating Temp. Range-10℃~+50℃
    Temp. Measuring Rang-20℃~+120℃-20℃~+120℃(extended to 400℃)
    Temp. Measuring Accuracy±3℃or±3% of temperature measuring range±2℃or±2% of temperature measuring range
    Temp. CorrectionManual/Auto
    Power Consumption, mW<500
    Weight (with lens), g<40
    Dimension (with lens), mm49.5*26*27.549.5*26*3026*26*26
    Phone CompatibilityAndroid 6.0 or above*
    Image EnhancementDigital enhancement
    Image CalibrationManual/Auto(per 3 min when no manual   operation)
    Color PaletteWhite hot/Black hot/Multiple pseudo color   options
    SDK DevelopSupport
    Temp. StatisticsSupport max./min./center temp. display, with up to three spots statistics
    Photo & VideoSupport photos/ video storage .etc
    Online Software UpdateSupport

    *Support the mainstream mobile phone system, part of the system untested.
